Fitting Reducer
Model : 5243
Category : EN1254 Copper Fitting
Product Description
| Item | D1xD2 | A | L1 | L2 |
|---|---|---|---|---|
| 8x6 | 8x6 | 17.0 | 6.5 | 5.3 |
| 10x6 | 10x6 | 17.0 | 6.5 | 5.3 |
| 10x8 | 10x8 | 16.0 | 8.0 | 6.8 |
| 12x6 | 12x6 | 21.5 | 6.5 | 5.3 |
| 12x8 | 12x8 | 20.0 | 8.0 | 6.8 |
| 12x10 | 12x10 | 19.5 | 9.0 | 7.8 |
| 14x10 | 14x10 | 24.0 | 9.2 | 7.8 |
| 14x12 | 14x12 | 23.0 | 10.0 | 8.6 |
| 15x8 | 15x8 | 26.5 | 8.2 | 6.8 |
| 15x10 | 15x10 | 24.0 | 9.2 | 7.8 |
| 15x12 | 15x12 | 24.0 | 10.0 | 8.6 |
| 16x10 | 16x10 | 26.0 | 9.2 | 7.8 |
| 16x12 | 16x12 | 26.0 | 10.0 | 8.6 |
| 16x14 | 16x14 | 26.2 | 12.0 | 10.6 |
| 18x10 | 18x10 | 30.0 | 9.4 | 7.8 |
| 18x12 | 18x12 | 29.0 | 10.2 | 8.6 |
| 18x14 | 18x14 | 29.0 | 12.2 | 10.6 |
| 18x15 | 18x15 | 29.0 | 12.2 | 10.6 |
| 18x16 | 18x16 | 25.0 | 12.2 | 10.6 |
| 22x10 | 22x10 | 35.0 | 9.6 | 7.8 |
| 22x12 | 22x12 | 34.0 | 10.4 | 8.6 |
| 22x14 | 22x14 | 34.0 | 12.4 | 10.6 |
| 22x15 | 22x15 | 34.0 | 12.4 | 10.6 |
| 22x16 | 22x16 | 34.0 | 12.4 | 10.6 |
| 22x18 | 22x18 | 35.0 | 14.4 | 12.6 |
| 28x10 | 28x10 | 43.0 | 9.6 | 7.8 |
| 28x12 | 28x12 | 44.0 | 10.4 | 8.6 |
| 28x14 | 28x14 | 43.0 | 12.4 | 10.6 |
| 28x15 | 28x15 | 42.0 | 12.4 | 10.6 |
| 28x16 | 28x16 | 42.0 | 12.4 | 10.6 |
| 28x18 | 28x18 | 39.5 | 14.4 | 12.6 |
| 28x22 | 28x22 | 42.0 | 17.2 | 15.4 |
| 35x12 | 35x12 | 56.0 | 10.6 | 8.6 |
| 35x15 | 35x15 | 53.2 | 12.6 | 10.6 |
| 35x18 | 35x18 | 52.4 | 14.6 | 12.6 |
| 35x22 | 35x22 | 49.0 | 17.4 | 15.4 |
| 35x28 | 35x28 | 49.0 | 20.4 | 18.4 |
| 36x28 | 36x28 | 54.0 | 20.4 | 18.4 |
| 42x15 | 42x15 | 61.0 | 12.8 | 10.6 |
| 42x18 | 42x18 | 60.0 | 14.8 | 12.6 |
| 42x22 | 42x22 | 60.5 | 17.6 | 15.4 |
| 42x28 | 42x28 | 59.5 | 20.6 | 18.4 |
| 42x35 | 42x35 | 57.7 | 25.2 | 23.0 |
| 54x15 | 54x15 | 61.6 | 13.0 | 10.6 |
| 54x22 | 54x22 | 65.0 | 17.8 | 15.4 |
| 54x28 | 54x28 | 76.0 | 20.8 | 18.4 |
| 54x35 | 54x35 | 72.0 | 25.4 | 23.0 |
| 54x42 | 54x42 | 71.5 | 29.4 | 27.0 |
| 64x35 | 64x35 | 38.5 | 25.4 | 23.0 |
| 64x42 | 64x42 | 34.5 | 29.4 | 27.0 |
| 64x54 | 64x54 | 29.5 | 34.4 | 32.0 |
| 67x35 | 67x35 | 47.0 | 25.4 | 23.0 |
| 67x42 | 67x42 | 38.5 | 29.4 | 27.0 |
| 67x54 | 67x54 | 34.5 | 34.4 | 32.0 |
| 70x42 | 70x42 | 36.5 | 31.4 | 27.0 |
| 70x54 | 70x54 | 33.0 | 36.4 | 32.0 |
| 70x64 | 70x64 | 29.0 | 37.7 | 33.3 |
| 76.1x35 | 76.1x35 | 44.5 | 27.4 | 23.0 |
| 76.1x42 | 76.1x42 | 41.5 | 31.4 | 27.0 |
| 76.1x54 | 76.1x54 | 36.5 | 36.4 | 32.0 |
| 76.1x64 | 76.1x64 | 32.0 | 37.7 | 33.3 |
| 76.1x67 | 76.1x67 | 25.0 | 37.7 | 33.3 |
| 80x42 | 80x42 | 51.5 | 31.4 | 27.0 |
| 80x54 | 80x54 | 44.5 | 36.4 | 32.0 |
| 80x64 | 80x64 | 33.0 | 37.7 | 33.3 |
| 80x67 | 80x67 | 41.0 | 37.7 | 33.3 |
| 88.9x54 | 88.9x54 | 41.0 | 36.4 | 32.0 |
| 88.9x64 | 88.9x64 | 41.5 | 37.7 | 33.3 |
| 88.9x76.1 | 88.9x76.1 | 35.5 | 37.9 | 33.5 |
| 106x54 | 106x54 | 62.5 | 37.0 | 32.0 |
| 106x67 | 106x67 | 57.0 | 38.3 | 33.3 |
| 106x80 | 106x80 | 61.0 | 38.5 | 33.5 |
| 108x54 | 108x54 | 55.5 | 37.0 | 32.0 |
| 108x64 | 108x64 | 49.0 | 38.3 | 33.3 |
| 108x67 | 108x67 | 48.0 | 38.3 | 33.3 |
| 108x76.1 | 108x76.1 | 43.5 | 38.5 | 33.5 |
| 108x88.9 | 108x88.9 | 41.0 | 52.5 | 47.5 |
| 159x108 | 159x108 | 152.5 | 53.5 | 47.5 |
